EN-999 Hi-Phos Electroless Nickel Plating Process

2017-12-16

Code：EN-999

Name：EN-999 Hi-Phos Electroless Nickel Plating Process

1. The phosphorus content in deposits is up to 10.5-12%. It is adapted for high anti-corrosion products.

2. Semi-bright, non-magnetic, no fine pores, low stress, especially good for EMI shading plating, such as computer disk and etc.

3. Exhibits high hardness up to 500-600HV, even 900-1000HV after heat treatment, strong wear resistance.

4. Quick brightening, with the high deposition rate up to 10-18um/H.

Open the cylinder: EN-999A 50-70ml/L, EN-999B 160-200ml/L.

Consumption per square decimeter of workpiece deposited 10um coating thickness, need to add 8-10ml EN-999A and equal EN-999C.
